Application:
- For open wiring and raceways(except cable throughs and ventilated flexible cableway) in dry or wet locations.
- For exposed wiring where exposed to weather with sunlight resistant insulation. Approved for use with ceiling fixtures.
Structure:
- Conductor: Annealed bare copper wires or compact aluminum 8000 series wires
- Insulation: Cross-Linked Polyethylene (XLPE)
Standard:
- CSA Standard C22.2 No.38（Thermoset-Insulated Wires and Cables）
Performance:
- Sun Res(SR), Cold(-40C)
Details
| Material | Aluminum, Copper |
|---|---|
| Voltage | 1000V, 600V |
| Working temperature | -40ºC MIN, 90°C MAX |
